Hastelloy B-2

Hastelloy B-2 (N10665) is a nickel based high-temperature alloy composed of elements such as nickel, molybdenum, and cobalt, with a nickel content of approximately 65%. The alloy is a solid solution strengthened nickel molybdenum alloy. It has significant resistance to reducing environments such as hydrogen chloride gas, sulfuric acid, acetic acid, and phosphoric acid. Molybdenum is the main element with significant resistance to reducing environments. The alloy can be directly used after welding because it can resist the formation of carbide at the grain boundary of the welding Heat-affected zone. In addition, it has excellent resistance to pitting, stress corrosion cracking, knife edge corrosion and Heat-affected zone damage.

Product Description

1. Chemical Composition of Hastelloy B 2

Chemical Composition（wt. %）
Brands No.UNSCCrNiFeCoMnSiMo
Hastelloy B2N10665≤0.02%≤1.0%Balance≤2.0%≤1.0%≤1.0%≤0.1%26%~30%

2. Physical Properties:

　Physical propertiesMechanical Properties & Others
Brands No.Density g/cm3Melting pointYield StrengthTensile Strength MpaElongation A5 %Hardness  HRB
/℃Rp0.2(MPa)Rp1.0(Mpa)
Hastelloy B29.221330~1380350　76040　

3. Product Implementation Standards:

Trademark*MaterialUNSW.Nr.DensityTubePipe
smls/wldsmls/wld
Hastelloy B-2Alloy B-2N106652.46179.22B622/B626B622/B619

4. Specifications Available for Pipes and Tubes of Hastelloy B2 :

  • Seamless Tube: OD6-630 WT0.3-100mm
  • Capillary: OD0.2-6 WT0.02-2mm
  • Welded Pipe: on demand.

5. Applications

Hastelloy B2 is a nickel-molybdenum alloy that is particularly suitable for handling devices in chemical environments. It is used in the chemical processing industry with sulfuric acid, phosphoric acid, hydrochloric acid and acetic acid. Hastelloy B-2, collectively referred to as Hastelloy B-2 (Hastelloy) Hastelloy B-2 has the following properties Control the minimum levels of iron and chromium to make the B phase Ni4Mo. to prevent Excellent corrosion resistance to reducing environment Excellent resistance to medium-concentrated sulfuric acid and many non-oxidizing acids Very good resistance to chloride ion reduction Stress corrosion cracking Excellent corrosion resistance from various organic acids

6. Contact Us for More Information of Nickel Alloy Pipes and Tubes

As a Professional Nickel Alloy & Stainless Steel Pipes and Tubes Exporter, Southerly Special Alloy was founded in Dec-2021.Our core members have more than 5 years experience in Nickel Alloy and Stainless Steel manufacturing and related fields.We serve customers worldwide, our main markets are in Europe, Middle East, South East Asia, South America and Africa.

Please fill out the form below or send an email to  sales@southerly-alloy.com  for more information.

Key word: Alloy B 2, Hastelloy B 2, N10665, Seamless Tube, Welded Pipe, B622, B626, B619
